Vacuum Filter Stand Support Manufacturer,Supplier and Exporter in India
Product Code : EL-WS-10453
Last updated: 8 October 2026
The Vacuum Filter Stand Support is a self-standing stainless steel single-place manifold that holds one funnel and membrane for the vacuum filtration of water samples, with an outlet connection for the vacuum line. It is listed in the Water and Sanitation range and is specified for microbiological field water testing.
Specifications
| Specification | Value |
|---|---|
| Type | Self-standing stainless steel manifold and stand |
| Places | One, single place |
| Holds | Cup or funnel and membrane |
| Function | Membrane filtration of water samples by vacuum |
| Outlet | Outlet connection for the vacuum line |
| Material | Stainless steel |
| Application | Microbiological field water testing |
| Mounting | Self-standing, no bench clamp required |
Used for
Membrane filtration of a measured water sample, where the membrane is then transferred to a plate and incubated for a coliform count. The single place suits field work and low-throughput benches rather than batch runs, and because the stand is self-standing it needs no clamp or bench fixing on site. The incubation step runs on the Portable Water Quality Test Kit, which holds the coliform incubator; chlorine and pH are read separately on the Emergency Water Testing Kit. Raw water reaching the stand is often pre-filtered through a Water Filter, Candle Type.
Packing and documentation
Supplied in institutional quantities against a purchase order. School Instrument India states on its ordering pages that consignments carry a tracking ID and courier details until delivery. Mixed water and sanitation lots are quoted through the Tenders page.
Related items
- Portable Water Quality Test Kit — coliform incubator at 44 C, plus pH, chlorine and conductivity.
- Emergency Water Testing Kit — chlorine 0.1 to 3.0 mg/l and pH 6.8 to 8.2, 250 tests each.
- Water Filter, Candle Type — four silver-impregnated ceramic elements, up to 80 litres per day.
- Collapsible Water Container — 10 litres, PVC-coated polyester, UV resistant.
- Water Tank Collapsible — 10 CBM, polyester with PVC coating.
- Counting chamber, Neubauer — double improved grid, 9 mm3 area, 0.1 mm depth.
- Transfer Pipette — 5.8 ml, fine tip, integrated suction bulb.
- Cover glass — 0.17 mm thick, 22 x 22 mm, washed and polished.
- Electrical Submersible Pump — borehole pump, motor up to 7.5 kW.
- Water and Sanitation — the full pumps, tanks, valves, fittings and taps range.
- Clinical Laboratory — incubators, analysers and bench equipment.
- Glassware & Plasticware — vessels, dishes and laboratory consumables.
Questions buyers ask
How many filtration places does this manifold have?
One. It is a single-place manifold holding one cup or funnel and one membrane.
What is it made of?
Stainless steel, and it is self-standing, so it needs no bench clamp.
How does the vacuum connect?
Through an outlet connection on the support, which draws the sample through the membrane.
What is it used for?
Vacuum filtration of water samples for microbiological field water testing, ahead of incubating the membrane.
Does it include the incubator?
No. The incubator is part of the Portable Water Quality Test Kit.
Can it be ordered with the rest of a field testing set-up?
Yes. Send the stand, the test kit and any filtration consumables as one list through the contact page.
Request a quotation
Send the quantity required through the contact page. Buyers can request the latest copies of ISO certificates from School Instrument India.
