Clinometer Compass Manufacturer,Supplier and Exporter in India
Product Code : SCL-ELE-12015
The Clinometer Compass
is a precision-calibrated field instrument engineered for the empirical
measurement of vertical angles, slope inclinations, and magnetic bearings.
Designed for Secondary, Vocational TVET, and University-level surveying modules,
it facilitates the practical application of trigonometry in height and distance
calculations. This ISO-compliant instrument ensures accuracy for institutional
STEM curricula and civil engineering prerequisites.
Technical Specifications
|
Tender Specification |
OEM Technical Detail |
|
Material Grade |
Ruggedized Impact-Resistant
Composite / UV-Stabilized Polymer |
|
Measurement Range |
Dual-Scale: 0-90° Vertical
(Clinometer) and 360° Horizontal (Compass) |
|
Damping Mechanism |
Liquid-Damped or
Induction-Damped for Rapid Needle Stabilization |
|
Sighting System |
Integrated Prism or V-Notch
for High-Precision Target Alignment |
Key Pedagogical Outcomes
·
Integrated
Pendulum Clinometer Scale:
Allows students to determine the height of inaccessible objects via the Tangent
function, supporting in "Trigonometric Problem Solving."
·
Magnetic
Bearing Compass: Facilitates the
synthesis of navigational plotting and vector addition, supporting
"Advanced Geometry."
·
Multi-Axis
Sighting Mirror/Prism:
Enables simultaneous reading of the degree scale while sighting a target,
reinforcing "Precision Surveying and Data Collection" techniques.
International Logistics & Compliance
To maintain the
calibration of the magnetic needle and the structural integrity of the sighting
prisms during transcontinental maritime transit, all units are secured in
high-density protective cases and consolidated in export-grade seaworthy
crating (ISPM-15 compliant). International procurement documentation includes
the Manufacturer’s Authorization Form (MAF), IQ/OQ/PQ Certification (verifying
angular tolerance), and User Manuals in English. The instrument features a
tropicalized design, tested for operation in environments reaching 45°C and 90%
Humidity to ensure zero needle seizing or internal fogging in extreme climates.
